Ergonomical
Heavy Duty Patio Doors

Modern frame apertures are getting bigger and the demand for more glass and less vertical
divisions by frame members is increasing. ENCRAFT's Heavy Duty Patio Doors can comply with
those new challenges with its 2- pane version that can be manufactured up to 5.8 meters wide
and up to 3.0 meters tall. accepting a maximum sash weight of 300 kg. The overall outer frame
depth of 142 mm housing two 62 mm deep sashes is perfectly suited for modern straight
through apertures. The effortless operation of the heavy sashes achieved by using tandem
rollers with a high weight carrying capacity. ENCRAFT's solid Aluminum threshold construction
and a good gripping D-handle. anchored into the concealed sash steel.

Ÿ Available options 2-track (142 mm depth). 3-track (222 mm depth) and 4-track (302 mm)
Ÿ Unique Aluminum low threshold option for 2-track. 3-track and 4-track
Ÿ Internal glazing option from 4 mm single to 36 mm double
Ÿ Aluminum interlock for added rigidity equipped with double seal
Ÿ Heavy-duty tandem roller and multi-point lock as standard
Ÿ Optional mosquito screen and/or centre-pane/4-panel adapter

French Doors

ENCRAFT French Doors. also known as double doors or double windows. are a pair of glass
doors usually opening from the back of a house into its garden or onto its balcony. This concept
of opening both sashes fully without seeing a centre obstruction has influenced French
architecture since the 17th century. The whole grace and dignity of many European buildings
was based on this majestic design principle. Modern fenestration adopted the uniqueness of
French doors and French windows. mainly upgrading the design for high performance glazing
and sophisticated locking devices whilst retaining the original character.

Ÿ ENCRAFT casement sashes are suitable for French doors and French windows
Ÿ Available in opening-out and open-in mode
Ÿ Internal glazing option from 4 mm single to 36 mm double
Ÿ Choice of numerous multi-point locking devices including full perimeter locking
Ÿ French doors are available threshold-less or with Aluminum low threshold
Ÿ Choice of hinge types including concealed (invisible) hinges
